- FIRST TIME IN PAKISTAN PV INVERTER SUPPORT BIGGEST SIZE SOLAR PANELS 1000W
- PURE SINE WAVE SOLAR INVERTER
- CAN WORK IN ON / OFF GRID MODE
- BUILD IN HIGH EFFICIENCY MPPT SOLAR CONTROLLER
- WIDE PV INPUT VOLTAGE : 60 - 500VDC
- DUAL MPPT SOLAR CONTROLLER FOR DIFFERENT GROUPS SOLAR PANEL
- LCD DISPLAY ALL INFORMATION ON ONE INTERFACE
- BUILD IN FEEDBACK DETECTION CURRENT SENSOR
- COMMUNICATION INTERFACE FOR WIFI OPTIONAL
- FAST ISLANDING RESPONSE ENSURES SECURITY
- EASY TO REPLACE DUST SCREEN DESIGN
- BATTERY INDEPENDENT DESIGN, NO NEED BATTERY
- SUPPORT TOPCON / HJT / HIMO10 PANELS
- GRID FEEDING BACK TO GRID
- MADE IN TAIWAN
| SPECIFICATION | |
|---|---|
| Phase | Single-Phase |
| Rated Output Power | 5KVA |
| PV MODE | |
| Number of MPPT | 1 |
| Maximum PV Input Current | 27A |
| PV Array Maximum Open Circuit Voltage | 500VDC |
| PV Input Voltage Range | 60-500VDC |
| Start Up Voltage | 120VDC |
| Nominal DC Voltage | 360VDC |
| MPPT Trackers Efficiency | >99.5% |
| LINE MODE | |
| Voltage | 230VAV |
| Input Voltage Range | 90-280VAC |
| Input Frequency Range | 40-65Hz |
| Maximum Input Current | 20A |
| Input Power Factor | >0.99 |
| Input THDi | <5% |
| PROTECTION | |
| Full Protection | Overload, Short Circuit, Over-temperature, Over-current, Anti-Islanding Protection |
| PHYSICAL | |
| Dimension H x W x D (mm) | 315.5 x 225 x 103 |
| Cartoon Dimension H x W x D (mm) | - |
| Net Weight (kgs) | 3.5 |
| Gross Weight (kgs) | - |
| IP Protection | IP40 |
| INTERFACE | |
| Communication Port | RS-232 |
| ENVIRONMENT | |
| Humidity | <95% RH(Non-Condensing) |
| Operating Temperature | -10°C to 55°C |
